The 3500/72M reciprocating rod position monitor is a high-performance monitoring device that is part of its 3500 series monitoring system. This monitor is designed specifically to monitor the vibration and position changes of large rotating machinery (such as reciprocating compressors, gas compressors, etc.), and plays an important role in ensuring the safe operation of industrial equipment.

Many products have not been listed yet. For more products, please contact us

If the product model is inconsistent with the displayed image, the model shall prevail. Please contact us for specific product images, and we will arrange for photos to be taken and confirmed in the warehouse

We have 16 shared warehouses worldwide, so sometimes it may take several hours to accurately return to you. We apologize for any inconvenience caused. Of course, we will respond to your concerns as soon as possible.

3500/72M also known as:

Real time monitoring device for reciprocating rod position 3500/72M

3500/72M Rod position monitor

Pole position monitoring instrument 3500/72M

3500/72M Piston rod position monitor

4-channel monitor 3500/72M

The 3500/72M reciprocating rod position monitor is a four channel monitor that receives input signals from proximity sensors, adjusts these signals to provide dynamic and static position measurements, and compares the adjusted signals with user programmable alarm settings.

This type of monitor plays an important role in protecting the mechanical components of reciprocating compressors, preventing faults, and ensuring safe equipment operation.

The main functions of the 3500/72M reciprocating rod position monitor are:

Measurement of piston rod position:

Monitoring the position change of the piston rod to ensure it is within the normal operating range is crucial for the normal operation of the machinery.

Receive input signals from proximity sensors and adjust these signals to provide dynamic and static position measurements.

Measurement of piston rod drop:

Monitoring the position change of the piston rod during the descent process helps prevent mechanical damage caused by excessive falling.

Measurement of ultra-high pressure compressor:

Monitor the working status of the high-pressure compressor to ensure it operates within a safe pressure range.

Alarm and protection:

Compare the adjusted signal with the user programmable alarm settings. When the monitoring parameters exceed the set range, drive the alarm and trigger the relay to achieve mechanical protection of the reciprocating compressor.

Technical characteristics of the 3500/72M reciprocating rod position monitor:

Four channel monitoring:

The 3500/72M is a four channel monitor that can simultaneously monitor multiple position parameters, improving the accuracy and reliability of monitoring.

Programmability:

Users can program each channel of the monitor through the 3500 rack configuration software, set alarm and danger setpoints to meet different monitoring needs.

High-precision:

Adopting advanced signal conditioning technology and high-precision sensors to ensure the accuracy and reliability of monitoring results.

Easy to install and maintain:

The monitor is compact in design, easy to install, and provides a user-friendly interface and easily understandable alarm information, making it easy for maintenance personnel to carry out daily maintenance and troubleshooting.

Configuration of 3500/72M reciprocating rod position monitor:

Hardware connection:

Install the monitor into the appropriate slot of the 3500 series rack and ensure a secure and reliable connection to the rack.

Install proximity sensors (such as reluctance sensors, Hall sensors, etc.) on the reciprocating compressor to detect the position of the piston rod, and connect the sensor signal to the input of the monitor.

Software configuration:

Program and set up the monitor using 3500 rack configuration software (or other designated configuration tools).

Configure the channel parameters of the monitor, including signal type, measurement range, filtering settings, etc., to ensure accurate measurement of the position of the piston rod.

Set alarm points and alarm logic. According to the operating characteristics and safety requirements of reciprocating compressors, appropriate alarm points should be set and corresponding alarm logic should be configured to timely send out alarm signals when the piston rod position exceeds the normal range.

System testing:

After completing the configuration, it is necessary to conduct comprehensive testing on the monitor to verify its performance and reliability.

During the testing process, different piston rod positions and motion states can be simulated to check the measurement accuracy and alarm function of the monitor.

Document records:

Record the configuration process and setting parameters of the monitor for subsequent maintenance and troubleshooting.

Application fields of 3500/72M reciprocating rod position monitor:

The oil and gas industry:

In the process of oil and gas extraction, processing, and transportation, reciprocating compressors are widely used to compress gases. The 3500/72M monitor can monitor the position of the piston rod in real-time, ensuring the stable operation of the compressor and preventing faults caused by abnormal piston rod position.

Chemical and petrochemical industries:

In these industries, reciprocating compressors are commonly used for gas compression in various process flows. By installing a 3500/72M monitor, the operation status of the compressor can be monitored in real time, potential problems can be identified and dealt with in a timely manner, ensuring production safety.

Refrigeration and Air Conditioning Industry:

In large-scale refrigeration and air conditioning systems, reciprocating compressors also play an important role. The 3500/72M monitor ensures efficient operation of the compressor and reduces downtime caused by mechanical failures.

Other industrial sectors:

In addition to the aforementioned industries, the 3500/72M reciprocating rod position monitor can also be used in other industrial fields that require precise control of piston rod position, such as metallurgy, power, etc.

In summary, the 3500/72M reciprocating rod position monitor plays an important role in the mechanical protection and status monitoring of reciprocating compressors through its precise measurement and reliable alarm function. It has a wide range of applications, covering multiple important industries such as oil, natural gas, chemical, and petrochemical.
