Industrial computer boards are the core components of computer systems, responsible for connecting various hardware devices and providing functions for data transmission, control, and management. Compared with ordinary home or commercial computer motherboards, industrial computer boards have significant advantages in stability, durability, and environmental adaptability.
Many products have not been listed yet. For more products, please contact us
If the product model is inconsistent with the displayed image, the model shall prevail. Please contact us for specific product images, and we will arrange for photos to be taken and confirmed in the warehouse
We have 16 shared warehouses worldwide, so sometimes it may take several hours to accurately return to you. We apologize for any inconvenience caused. Of course, we will respond to your concerns as soon as possible.
VMIVME-7750 VMIVME-7750-760000 also known as:
Industrial computer board VMIVME-7750 VMIVME-7750-760000
VMIVME-7750 VMIVME-7750-760000 Industrial grade computer motherboard
Computer motherboard VMIVME-7750 VMIVME-7750-760000
VMIVME-7750 VMIVME-7750-760000 Industrial motherboard
Industrial embedded motherboard VMIVME-7750 VMIVME-7750-760000
VMIVME-7750 VMIVME-7750-760000 VMEbus Industrial Computer Board is an industrial computer board based on the VMEbus standard. It combines the electrical standards of Motorola's Versabus universal bus and the mechanical shape factor of the Eurocard standard established in Europe, providing a high-speed, reliable, and modular microcomputer system architecture for industrial control, digital systems, and other fields.
.jpg)
Working principle of VMIVME-7750 VMIVME-7750-760000 VMEbus industrial computer board:
Bus standards and structures:
The VMEbus standard combines the electrical standards of Motorola's Versabus universal bus with the mechanical shape factor of the Eurocard standard established in Europe.
It defines a system that can interconnect data processing, data storage, and connect peripheral control devices in a tightly coupled hardware architecture.
The mechanical structure of VMEbus mainly includes a backplane, which has three sizes: 3U, 6U, and 9U. The connectors on the backplane mainly include P0/J0, P1/J1, and P2/J2. The P1/J1 and P2/J2 connectors have 96 pins arranged in three rows, with 32 pins in each row; The P0/J0 connector has 95 pins.
Data transmission mechanism:
The data transmission mechanism of VMIVME-7750 VMIVME-7750-760000 VMEbus industrial computer board is asynchronous, with multiple bus cycles. The address width can be 16, 24, 32, 40, or 64 bits, and the data line width can be 8, 16, 24, 32, or 64 bits. The system can dynamically select them.
The data transmission method is asynchronous and is only subject to the signal exchange protocol, without relying on the system clock.
The transmission rate varies depending on different versions, for example, the transmission rate of VME64 can reach 320MB/s, while the transmission rate of VME320 can reach 3200MB/s.
System composition and functions:
The VMEbus system consists of multiple submodules, including CPU, memory, input/output interfaces, etc.
The bus controller is responsible for controlling the access and data transmission of the bus, while the bus arbiter is responsible for coordinating the usage rights of various modules on the bus.
.jpg)
Advantages of VMIVME-7750 VMIVME-7750-760000 VMEbus Industrial Computer Board:
High integration:
The VMIVME-7750 VMIVME-7750-760000 VMEbus industrial computer board adopts a modular design, and the VMEbus system can integrate a large number of functions in limited space, making it suitable for embedded and industrial applications with limited space.
Easy to maintain and upgrade:
The modular design of the VMEbus system makes maintenance and upgrades easier. Users can improve system performance or add new features by replacing or upgrading individual cards without replacing the entire system.
Long lifespan and stability:
The VMEbus system has undergone rigorous testing and verification, with a long service life and stable performance. This makes it an ideal choice for applications that require long-term operation and reliability.
Cost effectiveness:
Although the initial investment of VMEbus systems may be relatively high, due to their high performance, reliability, and ease of maintenance, they are typically able to provide lower total cost of ownership (TCO) in the long term.
The development trend of VMIVME-7750 VMIVME-7750-760000 VMEbus industrial computer boards:
With the development of industrial intelligence, the VMIVME-7750 VMIVME-7750-760000 VMEbus industrial computer board is becoming increasingly intelligent, integrating more sensors and control modules to achieve more complex functions.
While pursuing high performance, there is also an increasing emphasis on energy conservation and environmental protection. The VMIVME-7750 VMIVME-7750-760000 VMEbus industrial computer board reduces system power consumption through optimized design and the use of low-power technology.
The future industrial motherboards will pay more attention to safety and adaptability, and can automatically adjust parameters and settings according to different environments and task requirements.
In summary, VMIVME-7750 VMIVME-7750-760000 VMEbus industrial computer board is an industrial computer motherboard based on the VMEbus standard, characterized by high-speed data transmission, modular design, compatibility and interoperability, reliability, and rich interfaces and expansion slots. It is widely used in industrial automation, military systems, transportation, medical equipment, and energy management, providing a solid foundation for system design and development in these fields.
